Sabo Bridge remains closed over safety concerns

Bridge cable failure closes light rail tracks
Train tracks for the light rail pass under the Martin Olav Sabo Bridge Wednesday, Feb. 22, 2012, as workers attempt to stabiilze the bridge after one of its support cable broke loose Sunday night. Light-rail service was suspended between the 38th Street and Franklin Avenue stations, along with traffic on Hiawatha Avenue between 26th and 28th Streets.
MPR Photo/Alex Kolyer

Bridge experts are evaluating the safety of the Martin Olav Sabo Bridge in Minneapolis to determine when the pedestrian and bicycle crossing can reopen.

City crews Thursday completed installing support structures beneath the bridge, where a suspension cable connection broke loose late Sunday. Crews also released tension from a second pair of compromised cables.

Minneapolis crews plan to remove the compromised cables on the Sabo bridge Friday.

Inspectors are working methodically to assess the bridge's condition, strength and ability to handle movement, Assistant Hennepin County Public Works Administrator Debra Brisk said. Investigators are also inspecting the remaining cables along the bridge.

Create a More Connected Minnesota

MPR News is your trusted resource for the news you need. With your support, MPR News brings accessible, courageous journalism and authentic conversation to everyone - free of paywalls and barriers. Your gift makes a difference.

"They are being very cautious, because one little error and you may have some cables that are flying or you could have something happen to the bridge itself," Brisk said.

The city and county brought in Illinois-based Wiss, Janney, Elstner Associates to help investigate the Sabo bridge failure. The contract for forensic engineering stipulates the cost won't exceed $100,000.

The firm has expertise in emergency investigations, and also investigated the 35W bridge collapse in 2007.

Hiawatha Avenue and 26th Street detours
A sign at Hiawatha Avenue and 26th Street detours drivers around Hiawatha Avenue Wednesday, Feb. 22, 2012, while workers attempt to stabilze the Martin Olav Sabo Bridge after a support cable broke loose from the bridge Sunday night. The road is closed between 26th Street and 28th Street along with light-rail service between the 38th Street and Franklin Avenue stations.
MPR Photo/Alex Kolyer

That is also the same year the Sabo bridge was built. Documents obtained by MPR News show inspections of the $5.1 million Sabo Bridge in October 2011 by the city's licensed bridge inspectors found the span's superstructure, cables and supports to be in good condition.

That a bridge less than five years old would have problems is surprising to New York-based bridge engineer Andrew Coates, partner and chief technical officer for Hardesty & Hanover. He said investigators will have to determine what caused the cable support to fail.

"Poor construction or fabrication, a weld wasn't made right. There could be a fatigue issue due to vibrations caused by wind or something else," Coates said. "You know, the classic fatigue thing is you bend a paperclip back and forth until finally you break it."

San Francisco-based URS Corp. consulted on the design of the cable-stayed bridge. That's the same company that consulted on the 35W bridge. The Sabo bridge was built by Burnsville-based Ames Construction.

Neither Ames nor URS returned calls seeking comment.

The Sabo Bridge is the only cable-stayed bridge in the state.

The federal government does not track how many other cable-stayed pedestrian bridges there are across the country. In 2007, there were around 30 cable-stayed vehicle bridges nationwide.

Minnesota state bridge engineer Nancy Daubenberger says any issues uncovered by the investigation of the Sabo bridge will be helpful.

Hiawatha Line rider alert
Commuters transferring at the 38th Street station board a bus instead of using the light-rail due to the closing of light-rail service between the 38th Street and Franklin Avenue stations. Light-rail service was suspended after a support cable on the Martin Olav Sabo Bridge - which spans above Hiawatha Avenue and the light-rail line - broke loose Sunday night.
MPR Photo/Alex Kolyer

"It is a bridge design that has a very high aesthetic value. I think cable bridges in general are viewed as very aesthetic bridges and there's been success with cable designs across the country," Daubenberger said. There is no reason it shouldn't have been considered here. It's just something we need to know more about."

City officials say it is unclear how long the investigation could take.

While it continues, the city is diverting traffic on Hiawatha Avenue. The Lake Street stop on the Hiawatha light rail line remains closed. Shuttle buses are replacing light rail service between 38th Street and Franklin Avenue.
